Omron CS1W-AD081-V1 User Manual

32
Wiring Section 2-4
2-4 Wiring
2-4-1 Terminal Arrangement
The signal names corresponding to the connecting terminals are as shown in
the following diagram.
CS1W-AD041-V1
CS1W-AD081-V1
Input 2 (+)
Input 2 (–)
Input 4 (+)
Input 4 (–)
N.C.
N.C.
N.C.
N.C.
Input 1 (+)
Input 1 (–)
Input 3 (+)
Input 3 (–)
AG
N.C.
N.C.
N.C.
N.C.
B1
B2
B3
B4
B5
B6
B7
B8
B9
A1
A2
A3
A4
A5
A6
A7
A8
A9
AG
B10
N.C.
N.C.
N.C.
A10
A11
Input 2 (+)
Input 2 (–)
Input 4 (+)
Input 4 (–)
Input 6 (–)
AG
Input 8 (+)
Input 8 (–)
Input 1 (+)
Input 1 (–)
Input 3 (+)
Input 3 (–)
AG
Input 5 (+)
Input 5 (–)
AG
Input 7 (+)
B1
B2
B3
B4
B5
B6
B7
B8
B9
A1
A2
A3
A4
A5
A6
A7
A8
A9
AG
B10
Input 6 (+)
Input 7 (–)
N.C.
A10
A11
