15
Specifications Section 2-1
Note 1. Do not apply a voltage higher than 600 V to the terminal block when per-
forming withstand voltage test on this Unit. Otherwise, internal elements
may deteriorate.
2. Refer to Dimensions on page 359 for details on the Unit’s dimensions.
3. The maximum number of Analog Input Units that can be mounted to one
Rack depends on the Power Supply Unit mounted to the Rack.
The above limits may be reduced depending on the power consumed by
other Units on the same Rack.
Input
func-
tions
Mean value processing Stores the last “n” data conversions in the buffer, and stores the mean value of the
conversion values.
Buffer number: n = 2, 4, 8, 16, 32, 64
Peak value holding Stores the maximum conversion value while the Peak Value Hold Bit is ON.
Input disconnection
detection
Detects the disconnection and turns ON the Disconnection Detection Flag. (See note
11.)
Scaling function None None Enabled only for conver-
sion time of 1 ms and reso-
lution of 4,000. Setting any
values within a range of
±32,000 as the upper and
lower limits allows the A/D
conversion result to be out-
put with these values as
full scale.
Item CS1W-AD041-V1 CS1W-AD081-V1 CS1W-AD161
Power Supply Unit Rack CS1W-
AD041-V1
CS1W-
AD081-V1
(5 VDC
120 mA)
CS1W-DA041
CS1W-DA08V
(5 VDC
130 mA)
CS1W-
MAD44
(5 VDC
200 mA)
CS1W-DA08C
(5 VDC
130 mA)
CS1W-AD161
(5 VDC
150 mA)
C200HW-PA204
C200HW-PA204S
C200HW-PA204R
C200HW-PA204C
C200HW-PD024
(4.6 A at 5 VDC)
CPU Rack63328
Expansion Rack63329
C200HW-PA209R
(9 A at 5 VDC)
CPU Rack1076510
Expansion Rack1076510
CS1D-PA207R
(7 A at 5 VDC)
CPU Rack85448
Expansion Rack96549
CS1D-PD024
(4.3 A at 5 VDC)
CPU Rack63227
Expansion Rack63228
