Omron CS1W-AD081-V1

391
Data Memory Coding Sheets Appendix C
Note m=20000+ unit number x 100 is allocated as the DM number.
DM word
Setting contents
15 8 7
0
m
m+1
m+2
m+3
m+4
m+5
m+6
m+7
m+8
m+9
m+10
m+11
m+12
m+13
Input use
designation
Output use
designation
Output 1: Output status
when conversion stopped
Output 2: Output status
when conversion stopped
Input 1: Mean value processing setting
Input 2: Mean value processing setting
Loop 1 (input 1 → output 1), A constant
Loop 1 (input 1 → output 1), B constant
Loop 2 (input 2 → output 2), A constant
Loop 2 (input 2 → output 2), B constant
07 06 05 04 03 02 01 00
Input 2 Input 1
Output 2
Output 1
15 14 13 12 11 10 09 08
Loop 2 Loop 1
Use Designation
0: Do not use.
1: Use
00: Do not use.
01: Positive gradient conversion
10: Negative gradient conversion
11: Same as the above "00" setting
07 06 05 04 03 02 01 00
15 14 13 12 11 10 09 08
Input 2 Input 1
Signal Range Setting
00: −10 to 10 V
01: 0 to 10 V
10: 1 to 5 V / 4 to 20 mA (4 to 20 mA is for analog input only)
11: 0 to 5 V
Output 2 Output 1
B Constant
16-bit binary data
A Constant
0 to 9999 BCD (0.00 to 99.99; unit: 0.01)
07 04 03 00
16
1
16
0
00: CLR (0 or minimum value for each range output)
01: HOLD (Hold prior output value.)
02: MAX (Output maximum value of range.)
Output Status when Conversion Stopped
15 12 11 08 07 04 03 00
16
3
16
2
16
1
16
0
Mean Value Processing Setting
0000: Mean value processing with 2 buffers.
0001: No mean value processing
0002: Mean value processing with 4 buffers.
0003: Mean value processing with 8 buffers.
0004: Mean value processing with 16 buffers.
0005: Mean value processing with 32 buffers.
0006: Mean value processing with 64 buffers.
m+14
m+15
m+16
m+17
Loop 3 (input 3 → output 3), A constant
Loop 3 (input 3 → output 3), B constant
Loop 4 (input 4 → output 4), A constant
Loop 4 (input 4 → output 4), B constant
Output 3: Output status
when conversion stopped
Output 4: Output status
when conversion stopped
Input 3: Mean value processing setting
Input 4: Mean value processing setting
Ratio conversion
use designation
Input signal
range setting
Output signal
range setting
Input 4 Input 3
Output 4 Output 3
Loop 4 Loop 3
Output 4 Output 3
Input 4 Input 3
16-bit binary data
