Omron CS1W-AD081-V1 User Manual

71
Handling Errors and Alarms Section 2-8
Alarm Flags
n = CIO 2000 + unit number x 10
ERC and RUN Indicators: Lit
The ERC and RUN indicators will be lit when an error occurs while the Unit is
operating normally. The following alarm flags will turn ON in CIO word n+9.
These alarm flags will turn OFF automatically when the error is cleared.
n = CIO 2000 + unit number x 10
Note 1. These alarms are output in word n+9 for CS1W-AD041-V1 and CS1W-
AD081-V1, and in words n+18/n+19 for CS1W-AD161.
2. The CS1W-AD041-V1 uses bits 00 to 08 of word n+9, and the CS1W-
AD081-V1 uses bits 00 to 04. The CS1W-AD161 uses bits 00 to 15 of word
n+18.
3. The disconnection detection function is enabled for input numbers set with-
in the input ranges 1 to 5 V or 4 to 20 mA.
Model CS1W-AD041-V1
CS1W-AD081-V1
CS1W-AD161 Contents
Word n+9 n+19
Bit 15 15 Operating in adjustment mode.
14 14 EEPROM error occurred during
adjustment mode.
13 13 Input number setting error occurred
during adjustment mode.
12 12 Input adjustment value outside
range during adjustment mode.
11 11 Mean average processing error
occurred.
--- 08 Scaling data setting error occurred.
RUN
ERC
ERH
: Lit
: Not lit
Word n+9,
n+18, or n+19
(See note 1.)
Alarm flag Error contents Input status Countermeasure
Bits 00 to 07
(See note 2.)
Disconnection
Detection
A disconnection was detected.
(See note 3.)
Conversion data
becomes 0000.
Check the rightmost byte of CIO
word n+9. The inputs for bits
that are ON may be discon-
nected. Restore any discon-
nected inputs.
Bit 14 (Adjustment
mode)
EEPROM Writ-
ing Error
An EEPROM writing error has
occurred while in adjustment
mode.
Holds the values
immediately
prior to the error.
No data is
changed.
Turn the Set Bit OFF, ON, and
OFF again.
If the error persists even after
the reset, replace the Analog
Input Unit.
