DeviceNet Explicit Messages Appendix 1
Setting and Monitoring the Safety Output Point
Explicit
message
Read/
write
Function Command Response
Service
Code
Class
ID
Instance
ID
Attribute
ID
Data size
Te rm in al
Maintenance
Information
Monitor Mode
Read
Read Reads the monitor
mode for mainte-
nance information
of the output (1 to
8) specified by the
instance ID.
0E hex 3B hex 01 to 08
hex
65 hex - 1 byte
00 hex: Total ON
time mode
01 hex: Contact
operation
counter mode
Write Writes the monitor
mode for mainte-
nance information
of the output (1 to
8) specified by the
instance ID.
10 hex 3B hex 01 to 08
hex
65 hex 1 byte
00 hex: Total ON
time mode
01 hex: Contact
operation
counter mode
-
Output Set
Value for
Tota l ON
Time or Con-
tact Opera-
tion
Read Reads the set
value for the total
ON time (unit: s) or
number of contact
operations (unit:
operations) of the
output (1 to 8)
specified by the
instance ID.
0E hex 3B hex 01 to 08
hex
68 hex - 4 bytes
0000 0000 to
FFFF FFFF hex
(0 to
4,294,967,295)
Write Writes the set value
for the total ON
time (unit: s) or
number of contact
operations (unit:
operations) of the
output (1 to 8)
specified by the
instance ID.
10 hex 3B hex 01 to 08
hex
68 hex 4 bytes
0000 0000 to
FFFF FFFF hex
(0 to
4,294,967,295)
-
Output Total
ON Time or
Contact
Operation
Counter Read
Read Reads the set
value for the total
ON time (unit: s) or
number of contact
operations (unit:
operations) of the
output (1 to 8)
specified by the
instance ID.
0E hex 3B hex 01 to 08
hex
66 hex - 4 bytes
0000 0000 to
FFFF FFFF hex
(0 to
4,294,967,295)
Output Total
ON Time or
Contact
Operation
Counter
Reset
Reset Resets the total ON
time or number of
contact operations
for time output (1 to
8) specified by the
instance ID.
05 hex 3B hex 01 to 08
hex
66 hex
