6 Parameters
6 - 40
E5@C Digital Temperature Controllers User’s Manual (H174)
PV/MV (Manual MV)
• The manual control level display appears as shown below.
E5EC/E5AC E5CC/E5CC-U/E5DC E5GC
* When the Manual MV Limit Enable parameter is set to ON, the
setting range will be the MV lower limit to the MV upper limit.
z
z Related Parameters
Standard or Heating/Cooling (Initial Setting Level): Page 6-45
z
Function
100
50.0
25
PV/SP/Manual MV
50.0
25
PV/Manual MV
50.0
25
PV/Manual MV
Monitor range Unit
Process value Temperature: According to indication range for each sensor.
Analog: Scaling lower limit −5% FS to Scaling upper limit +5% FS
(Refer to A-7 Sensor Input Setting Range, Indication Range, Con-
trol Range.)
EU
Set point SP lower limit to SP upper limit EU
Setting range Unit
MV (Manual MV) Standard control
Position-proportional control
−5.0 to 105.0* %
Heating/cooling control −105.0 to 105.0*
See
See
