A - 9
A Appendices
E5@C Digital Temperature Controllers User’s Manual (H174)
A-3 USB-Serial Conversion Cable and Conversion Cable
A
A-3-1 E58-CIFQ2 USB-Serial Conversion Cable
A-3 USB-Serial Conversion Cable and
Conversion Cable
A USB-Serial Conversion Cable is used to connect the E5@C to a computer. A Conversion Cable is
also required to connect to the Setup Tool port on the front panel of the E5EC, E5AC, or E5DC or to the
Setup Tool port on the bottom panel of the E5GC. The following table lists the cables and ports that are
used.
Refer to 2-4 Using the Setup Tool Port for the connection procedure.
z Specifications
Windows is a registered trademark of Microsoft Corporation in the United States and other
countries.
* Use a high-power port for the USB port.
Connection port Cable
Setup Tool port (card edge type) E58-CIFQ2 USB-Serial Conversion Cable
Setup Tool port (pin jack) E58-CIFQ2 USB-Serial Conversion Cable and E58-CIFQ2-E Conversion
Cable
A-3-1 E58-CIFQ2 USB-Serial Conversion Cable
Item Specifications
Applicable OS Windows 2000, XP, Vista, or 7
Applicable software CX-Thermo
Applicable models E5CC, E5EC, or E5AC: CX-Thermo version 4.5 or higher
E5DC: CX-Thermo version 4.6 or higher
E5CC-U or E5@C-T: CX-Thermo version 4.61 or higher
E5GC: CX-Thermo version 4.62 or higher
USB interface rating Conforms to USB Specification 2.0
DTE speed 38,400 bps
Connector
specifications
Computer end: USB (type A plug)
Digital Controller: Special serial connector
Power supply Bus power (Supplied from USB host controller)*
Power supply voltage 5 VDC
Current consumption 450 mA max.
Output voltage 4.7±0.2 VDC (Supplied through USB-Serial Conversion Cable to the Digital
Controller.)
Output current 250 mA max. (Supplied through USB-Serial Conversion Cable to the Digital
Controller.)
Ambient temperature 0 to 55°C (with no condensation or icing)
Ambient humidity 10% to 80%
Storage temperature −20 to 60°C (with no condensation or icing)
Storage humidity 10% to 80%
Altitude 2,000 m max.
Weight Approx. 120 g
