Omron E5C series - A-6-4 Manual Control Level

A Appendices
A - 24
E5@C Digital Temperature Controllers User’s Manual (H174)
*1 This range can be used only for E5CC-U Digital Controllers and only if they are manufactured in May
2014 or later (version 2.2 or higher).
*2 The remote SP will be output while the SP Mode parameter is set to the Remote SP Mode.
*3
*3.1 Initialized when the transfer output type is changed.
Initialized if the input type, temperature unit, scaling upper/lower limit, or SP upper/lower limit is changed
when the transfer output type is SP, ramp SP, or PV.
(When initialized by the initializing settings, it is initialized to 100.0/0.0.)
*4
*4.1 Initialized if the control output 1 type is changed.
Initialized if the input type, temperature unit, scaling upper/lower limit, or SP upper/ lower limit is changed
when the control output 1 type is set to the simple transfer SP, simple transfer ramp SP, or simple transfer
PV.
*5 PRST (Program Start) can be set even when the Program Pattern parameter is set to OFF, but the
function will be disabled.
*6 This function can be set for heating/cooling control or for floating control for Position-proportional Models,
but the setting will be disabled.
*1 When the Manual MV Limit Enable parameter is set to ON, the setting range will be the MV lower limit to the MV upper
limit.
*2 The valve opening is monitored for floating control or for close control with the Direct Setting of Position-proportional MV
parameter set to OFF.
Move to Advanced
function Setting Level
amov −1,999 to 9,999 0 None
Transfer output type Setting (monitor) range
Default
*3.1
(transfer output upper/lower
limits)
Unit
Set Point SP lower limit to SP upper limit SP upper limit/lower limit EU
Set Point During SP
Ramp
SP lower limit to SP upper limit SP upper limit/lower limit EU
PV Temperature input: Input setting range lower
limit to Input setting range upper limit
Input setting range upper/lower
limit
EU
Analog input: Scaling lower limit to Scaling
upper limit
Scaling upper/lower limit
MV (Heating) Standard: −5.0 to 105.0
Heating/cooling: 0.0 to 105.0
100.0/0.0 %
MV (Cooling) 0.0 to 105.0 100.0/0.0 %
Valve opening −10.0 to 110.0 100.0/0.0 %
Setting of the simple
transfer output type
Setting (monitor) range
Default
*4.1
(simple transfer output
upper/lower limits)
Unit
Simple transfer SP SP lower limit to SP upper limit SP upper limit/lower limit EU
Simple transfer ramp
SP
SP lower limit to SP upper limit SP upper limit/lower limit EU
Simple transfer PV Temperature input: Input setting range lower
limit to Input setting range upper limit
Input setting range upper/lower
limit
EU
Analog input: Scaling lower limit to Scaling
upper limit
Scaling upper/lower limit
Simple transfer MV
(heating)
Standard: −5.0 to 105.0
Heating/cooling: 0.0 to 105.0
100.0/0.0 %
Simple transfer MV
(cooling)
0.0 to 105.0 100.0/0.0 %
A-6-4 Manual Control Level
Parameters Setting (monitor) value Default Unit
Manual MV
−5.0 to 105.0 (standard)
*1
−105.0 to 105.0 (heating/cooling)
*2
−5.0 to 105.0 (position-proportional)
*1*2
0.0 %
Parameters Characters Setting (monitor) value Display Default Unit
