A-1 Specifications
A-1-1 Ratings
Supply voltage 100 to 240 VAC, 50/60 Hz 24 VAC, 50/60 Hz/24 VDC
Operating voltage range 85% to 110% of rated supply voltage
Power
consumption
E5CC/E5CC-U
Option number 000: 5.2 VA max.
Other option numbers: 6.5 VA max.
Option number 000: 3.1 VA max./1.6 W max.
Other option numbers: 4.1 VA max./2.3 W max.
E5EC
Option number 000: 6.6 VA max.
Other option numbers: 8.3 VA max.
Option number 000: 4.1 VA max./2.3 W max.
Other option numbers: 5.5 VA max./3.2 W max.
E5AC
Option number 000: 7.0 VA max.
Other option numbers: 9.0 VA max.
Option number 000: 4.2 VA max./2.4 W max.
Other option numbers: 5.6 VA max./3.4 W max.
E5DC 4.9 VA max. 2.8 VA max./1.5 W max.
E5GC 5.9 VA max. 3.2 VA max./1.8 W max.
Sensor input
*1
Thermocouple: K, J, T, E, L, U, N, R, S, B, W, PLII
Platinum resistance thermometer: Pt100, JPt100
Infrared temperature sensor: 10 to 70°C, 60 to 120°C, 115 to 165°C, 140 to 260°C
Current input
*2
: 4 to 20 mA, 0 to 20 mA (Input impedance: 150 Ω max.)
Voltage input
*2
: 1 to 5 V, 0 to 5 V, 0 to 10 V, 0 to 50 mV
*5
(Input impedance: 1 MΩ min.)
Control
output 1/2
*4
Relay
output
E5CC/E5DC
SPST-NO, 250 VAC, 3 A (resistive load), electrical life: 100,000 operations
Min. applicable load: 5 V, 10 mA
*3
(reference values)
E5CC-U
SPDT, 250 VAC, 3 A (resistive load), electrical life: 100,000 operations
Min. applicable load: 5 V, 10 mA (reference values)
E5EC/E5AC
SPST-NO, 250 VAC, 5 A (resistive load), electrical life: 100,000 operations
Min. applicable load: 5 V, 10 mA (reference values)
E5GC
SPST-NO, 250 VAC, 2 A (resistive load), electrical life: 100,000 operations
Min. applicable load: 5 V, 10 mA (reference values)
Voltag e
output
(for
driving
SSR)
E5CC/E5CC-U/
E5DC/E5GC
Output voltage 12 VDC ±20% (PNP), max. load current 21 mA, with short-circuit protection
circuit
E5EC/E5AC
Control Output 1
Output voltage 12 VDC ±20% (PNP), max. load current 40 mA, with short-circuit protection
circuit
(21 mA if there are two control outputs)
Control Output 2
Control output 2: 12 VDC ±20% (PNP), max. load current 21 mA, with short-circuit
protection circuit
Linear current output
4 to 20 mA DC, 0 to 20 mA DC, Load: 500 Ω max.
Resolution: Approx. 10,000 (E5CC/E5CC-U/E5EC/E5AC/E5DC/E5GC)
*3
Auxiliary
output
Relay
outputs
E5CC
2 or 3 auxiliary outputs (depends on model),
SPST-NO, 250 VAC, model with 2 auxiliary outputs: 3 A (resistive load), model with 3
auxiliary outputs: 2 A (resistive load),
Electrical life: 100,000 operations, Minimum applicable load: 10 mA at 5 V (reference values)
E5CC-U
1 or 2 auxiliary outputs (depends on model),
SPST-NO, 250 VAC, 3 A (resistive load),
Electrical life: 100,000 operations, Minimum applicable load: 10 mA at 5 V (reference values)
E5EC/E5AC
2 or 4 auxiliary outputs (depends on model),
SPST-NO, 250 VAC, model with 2 auxiliary outputs: 3 A (resistive load), model with 4
auxiliary outputs: 2 A (resistive load),
Electrical life: 100,000 operations, Minimum applicable load: 10 mA at 5 V (reference values)
E5DC
2 (depends on model)
SPST-NO, 250 VAC, 2 A (resistive load),
Electrical life: 100,000 operations, Minimum applicable load: 10 mA at 5 V (reference values)
E5GC
1 or 2 auxiliary outputs (depends on model),
SPST-NO, 250 VAC, 2 A (resistive load),
Electrical life: 100,000 operations, Minimum applicable load: 10 mA at 5 V (reference values)
Control method ON/OFF or 2-PID control (with autotuning)
Setting method Digital setting using front panel keys
Indication method 11-segment digital displays and individual indicators
Other functions Depend on the model
