Omron E5C series - Parameter Operation Lists; A-6-1 Operation Level

A Appendices
A - 18
E5@C Digital Temperature Controllers User’s Manual (H174)
A-6 Parameter Operation Lists
* Seconds can be set for the E5GC only.
A-6-1 Operation Level
Parameters Characters Setting (monitor) value Display Default Unit
Process Value Temperature: According to indication range for each
sensor.
Analog: Scaling lower limit
−5% FS to Scaling upper limit +5% FS
EU
Set Point SP lower limit to SP upper limit 0 EU
Multi-SP Set Point
Selection
m-sp 0 to 7 0 None
Remote SP Monitor rsp Remote SP lower limit −10%FS to remote SP upper limit
+ 10%FS
EU
Set Point During SP
Ramp
sp-m SP lower limit to SP upper limit EU
Heater Current 1 Value
Monitor
ct1 0.0 to 55.0 A
Heater Current 2 Value
Monitor
ct2 0.0 to 55.0 A
Leakage Current 1
Monitor
lcr1 0.0 to 55.0 A
Leakage Current 2
Monitor
lcr2 0.0 to 55.0 A
Program Start
prst RSET, STRT rset, strt RSET None
Soak Time Remain sktr 0 to 9999 s,* min,
or h
RUN/STOP r-s RUN/STOP run, stop Run None
Alarm Value 1 al-1 All alarms except for MV absolute-value upper-limit or
lower-limit alarms: −1,999 to 9,999
0EU
MV absolute-value upper-limit or lower-limit alarms:
−199.9 to 999.9
0.0 %
Alarm Value Upper Limit 1 al1h −1,999 to 9,999 0 EU
Alarm Value Lower Limit 1 al1l −1,999 to 9,999 0 EU
Alarm Value 2 al-2 All alarms except for MV absolute-value upper-limit or
lower-limit alarms: −1,999 to 9,999
0EU
MV absolute-value upper-limit or lower-limit alarms:
−199.9 to 999.9
0.0 %
Alarm Value Upper Limit 2 al2h −1,999 to 9,999 0 EU
Alarm Value Lower Limit 2 al2l −1,999 to 9,999 0 EU
Alarm Value 3 al-3 All alarms except for MV absolute-value upper-limit or
lower-limit alarms: −1,999 to 9,999
0EU
MV absolute-value upper-limit or lower-limit alarms:
−199.9 to 999.9
0.0 %
Alarm Value Upper Limit 3 al3h −1,999 to 9,999 0 EU
Alarm Value Lower Limit 3 al3l −1,999 to 9,999 0 EU
Alarm Value 4 al-4 All alarms except for MV absolute-value upper-limit or
lower-limit alarms: −1,999 to 9,999
0EU
MV absolute-value upper-limit or lower-limit alarms:
−199.9 to 999.9
0.0 %
Alarm Value Upper Limit 4 al4h −1,999 to 9,999 0 EU
Alarm Value Lower Limit 4 al4l −1,999 to 9,999 0 EU
MV Monitor (Heating) o −5.0 to 105.5 (standard)
0.0 to 105.0 (heating/cooling)
%
MV Monitor (Cooling) c-o 0.0 to 105.0 %
Valve Opening Monitor V-m −10.0 to 110.0 %
