A - 33
A Appendices
E5@C Digital Temperature Controllers User’s Manual (H174)
A-6 Parameter Operation Lists
A
A-6-9 Initialization According to Parameter Changes
*1 Initialized to input setting range upper and lower limits, or scaling upper and lower limits.
*2 Clamped by SP upper and lower limits.
*3 This parameter is initialized only when the input type is changed to analog input when the RT parameter is ON. The RT
parameter turns OFF.
*4 Initialization is performed as shown below according to the transfer output type setting. The initialization differs
depending on the changed parameter and the output type setting.
SP: SP upper and lower limits
Ramp SP: SP upper and lower limits
PV: Input setting range upper and lower limits or scaling upper and lower limits
MV (Heating): 100.0/0.0
MV (Cooling): 100.0/0.0
Valve opening: 100.0/0.0
*4.1 Initialized only when the transfer output type is set to SP, Ramp SP, or PV.
*4.2 Initialized only when the transfer output type is set to MV (Heating) or MV (Cooling).
*4.3 Initialized to the above default values regardless of the settings for changing the transfer output type.
*5 Initialized as follows according to the Standard or Heating/Cooling parameter setting.
MV Upper Limit: 100.0
MV Lower Limit: Standard 0.0, heating/cooling 100.0
*6 Initialized to control output (cooling) for heating and cooling control, according to the following.
(The defaults for standard control are the defaults in the parameter list.)
E5CC, E5CC-U, E5EC, E5AC, or E5DC
With control output 2: The Control Output 2 Assignment parameter is initialized to control output (cooling).
If the Digital Controller does not have control output 2 but has four auxiliary outputs, the Auxiliary Output 4
Assignment parameter is initialized to Control Output (Cooling).
If the Digital Controller does not have control output 2 but has two auxiliary outputs, the Auxiliary Output 2
Assignment parameter is initialized to Control Output (Cooling).
Otherwise, the Auxiliary Output 2 Assignment parameter is initialized to Control Output (Cooling).
E5GC
The Auxiliary Output 1 Assignment parameter is initialized to control output (cooling).
*7 If the Program Pattern parameter is set to OFF, the Auxiliary Output 1 Assignment parameter is initialized as follows:
Event Input
Assignment 1 to 6
--- --- --- --- --- ---
*8
--- --- --- --- --- --- --- --- --- --- ---
Move to Protect Level
--- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
*10
--- ---
MV Display Selection
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
Position Proportional
Dead Band
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
*20
---
Dead Band
*13
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
Hysteresis (Heating)
*13
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
Hysteresis (Cooling)
*13
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
Wait Band
*13
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
Alarm 1 to 4 Hysteresis
*14
--- --- --- --- --- --- --- --- --- --- --- ---
*15
--- --- --- ---
ST Stable Range
*13
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
AT H y st e re si s
*13
*18
*18
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
LBA Level
*13
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
LBA Band
*13
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
Simple Transfer Output
1 Upper Limit and
Simple Transfer Output
1 Lower Limit
*22
*22.1
*22.1
*22.1
*22.1
---
*22.2
--- --- --- ---
*22.3
--- --- --- --- --- --- ---
Input Type
Temperature Unit
Scaling Lower Limit
Scaling Upper Limit
SP Lower Limit
SP Upper Limit
PID ON/OFF
Standard or
Heating/Cooling
Program Pattern
ST
Remote SP Enable
Transfer Output Type
Control Output 1 Assignment
RT
Integral/Derivative Time Unit
Alarm 1 to 4 Type
SP 0 to 7
Set Point
Password to Move to
Protect Level
Close/Floating
Direct Setting of Position
Proportional MV
Related
initialized
parameters
Changed
parameter
