2 Preparations
2 - 4
E5@C Digital Temperature Controllers User’s Manual (H174)
z E5DC
The following figure shows the Terminal Unit attached to the Main Unit.
z E5GC
(85)
96
22.5
110
354
81
4
91
22.5
Adapter (sold separately)
24
48
63.6 4
1
1
90
22
40.8
44.8
22
24
48
63.6 4 93
22
40.8
44.8
22
Models with Screwless Clamp Terminal Blocks
Models with Screw Termial Blocks
