Omron E5CC-800 User Manual

3 Part Names and Basic Procedures
3 - 2
Digital Temperature Controllers (Simple Type) User’s Manual (H211)
3-1 Basic Application Flow
The following figure shows the basic flow for using the Digital Controller.
Power ON
• Input type
• Control method
• Alarm type
Other parameters
Set the set point.
Set the alarm set values.
Operate with the set values.
*For time-proportional operation.
Set the control hysteresis.
Set the control periods* and PID constants.
ON/OFF Control
PID Control
Set the input type and other basic
settings.
Refer to 3-4 Procedures after
Turning ON the Power Supply.

Omron E5CC-800 Specifications

General

Communication	RS-485 (optional)
Protection Rating	IP66 (front panel)
Input Type	Thermocouple, RTD, analog input
Output Type	Relay, voltage, current
Supply Voltage	100-240 VAC, 24 VAC/VDC
Size	48 x 48 mm
Control Output	Relay, voltage, current
Ambient Operating Temperature	55 °C
Control Method	ON/OFF, 2-PID
Ambient Operating Humidity	35 to 85% RH (non-condensing)
Mounting	Panel mount
