Digital Temperature Controllers (Simple Type) User’s Manual (H211)
A-5 Parameter Operation Lists
A
A-5-2 Adjustment Level
A-5-2 Adjustment Level
Parameters Characters Setting (monitor) value Display Default Unit
AT Execute/Cancel at OFF, AT Cancel
AT-2: 100%AT Execute
AT-1: 40%AT Execute
off, at-2,
at-1
OFF None
Communications
Writing
cmwt OFF, ON
off, on
OFF None
Heater Current 1 Value
Monitor
ct1 0.0 to 55.0 A
Heater Burnout
Detection 1
hb1 0.0 to 50.0 0.0 A
Leakage Current 1
Monitor
lcr1 0.0 to 55.0 A
HS Alarm 1 hs1 0.0 to 50.0 50.0 A
SP 0 sp-0 SP lower limit to SP upper limit 0 EU
SP 1 sp-1 SP lower limit to SP upper limit 0 EU
SP 2 sp-2 SP lower limit to SP upper limit 0 EU
SP 3 sp-3 SP lower limit to SP upper limit 0 EU
SP 4 sp-4 SP lower limit to SP upper limit 0 EU
SP 5 sp-5 SP lower limit to SP upper limit 0 EU
SP 6 sp-6 SP lower limit to SP upper limit 0 EU
SP 7 sp-7 SP lower limit to SP upper limit 0 EU
Process Value Input
Shift
ins Temperature input: −199.9 to 999.9 0.0 °C or °F
Analog input: −1,999 to 9,999 0 EU
Proportional Band p Temperature input: 0.1 to 999.9 8.0 °C or °F
Analog input: 0.1 to 999.9 10.0 %FS
Integral Time i Integral/Derivative Time Unit of 1 s: 0 to 9,999
Integral/Derivative Time Unit of 0.1 s: 0.0 to 999.9
233
233.0
Seconds
Derivative Time d Integral/Derivative Time Unit of 1 s: 0 to 9,999
Integral/Derivative Time Unit of 0.1 s: 0.0 to 999.9
40
40.0
Seconds
Proportional Band
(Cooling)
c-p Temperature input: 0.1 to 999.9 8.0 °C or °F
Analog input: 0.1 to 999.9 10.0 %FS
Integral Time (Cooling) c-i Integral/Derivative Time Unit of 1 s: 0 to 9,999
Integral/Derivative Time Unit of 0.1 s: 0.0 to 999.9
233
233.0
Seconds
Derivative Time
(Cooling)
c-d Integral/Derivative Time Unit of 1 s: 0 to 9,999
Integral/Derivative Time Unit of 0.1 s: 0.0 to 999.9
40
40.0
Seconds
Dead Band c-db Temperature input: −199.9 to 999.9 0.0 °C or °F
Analog input: −19.99 to 99.99 0.00 %FS
Manual Reset Value of-r 0.0 to 100.0 50.0 %
Hysteresis (Heating) hys Temperature input: 0.1 to 999.9 1.0 °C or °F
Analog input: 0.01 to 99.99 0.10 %FS
Hysteresis (Cooling) chys Temperature input: 0.1 to 999.9 1.0 °C or °F
Analog input: 0.01 to 99.99 0.10 %FS
SP Ramp Set Value sprt OFF, 1 to 9,999
off, 1 to
9999
OFF EU/s,
EU/min,
EU/h
MV Upper Limit ol-h MV lower limit +0.1 to 105.0 (standard)
0.0 to 105.0 (heating/cooling)
100.0 %
MV Lower Limit ol-l −5.0 to MV upper limit −0.1 (standard)
−105.0 to 0.0 (heating/cooling)
0.0
(standard)
−100.0
(heating/
cooling)
%
To Next Page
