Omron E5CC-800 User Manual

A Appendices
A - 4
Digital Temperature Controllers (Simple Type) User’s Manual (H211)
If the Waterproof Packing is lost or damage, order one of the following models.
A-1-3 Rating and Characteristics of Options
Event inputs
Contact Input
ON: 1 kΩ max., OFF: 100 kΩ min.
Non-contact Input
ON: Residual voltage 1.5 V max.; OFF: Leakage current 0.1 mA max.
Communications
Transmission path: RS-485
Communications method: RS-485 (2-wire, half duplex)
Synchronization: Start-stop
Baud rate: 9.6, 19.2, 38.4, or 57.6 kbps
A-1-4 Waterproof Packing
Y92S-P8 (for DIN 48 × 48) Y92S-P9 (for DIN 48 × 96)

Omron E5CC-800 Specifications

General

Communication	RS-485 (optional)
Protection Rating	IP66 (front panel)
Input Type	Thermocouple, RTD, analog input
Output Type	Relay, voltage, current
Supply Voltage	100-240 VAC, 24 VAC/VDC
Size	48 x 48 mm
Control Output	Relay, voltage, current
Ambient Operating Temperature	55 °C
Control Method	ON/OFF, 2-PID
Ambient Operating Humidity	35 to 85% RH (non-condensing)
Mounting	Panel mount
