A - 19
A Appendices
Digital Temperature Controllers (Simple Type) User’s Manual (H211)
A-5 Parameter Operation Lists
A
*1 Any settings that are entered will be ignored.
*2 The setting ranges are different for relay and voltage outputs (for driving SSR) and for current outputs.
*3 Do not set this value.
*4 The default setting is 4 when the settings are initialized.
PV Rate of Change
Calculation Period
pvrp 1 to 999 20 Sampling
period
Heating/Cooling Tuning
Method
hctm 0: Same as heating control
1: Linear
2: Air cooling
3: Water cooling
0 None
Minimum Output
ON/OFF Band
ompw 0.0 to 50.0 1.0 %
PF Setting pf OFF: OFF
RUN: RUN
STOP: STOP
R-S: RUN/STOP
AT-2: 100% AT execute/cancel
AT-1: 40% AT execute/cancel
LAT: Alarm Latch Cancel
A-M: Auto/manual
PFDP: Monitor/setting item
*3
SHFT: Digit Shift Key
off
run
stop
r-s
at-2
at-1
lat
a-m
pfdp
shft
SHFT None
PV/SP No. 1 Display
Selection
spd1 0: Nothing is displayed.
1: PV/SP/Nothing displayed
2: PV/Nothing displayed/Nothing displayed
3: SP/SP (character display)/Nothing displayed
4: PV/SP/MV
5: PV/SP/Multi-SP No.
6: PV/SP/Soak time remain
*1
7: PV/SP/Internal SP (ramp SP)
8: PV/SP/Alarm value 1
1
*4
None
PV/SP No. 2 Display
Selection
spd2 Same as PV/SP No. 1 Display Selection. 0 None
MV Display Selection odsl O: MV (Heating)
C-O: MV (Cooling)
o, c-o
0 None
PV Status Display
Function
pvst OFF: OFF
MANU: Manual
STOP: Stop
ALM1: Alarm 1
ALM2: Alarm 2
ALM3: Alarm 3
ALM4: Alarm 4
ALM: OR of alarms 1 to 4
HA: Heater alarm
*1
off
manu
stop
alm1
alm2
alm3
alm4
alm
ha
OFF None
SV Status Display
Function
svst OFF: OFF
MANU: Manual
STOP: Stop
ALM1: Alarm 1
ALM2: Alarm 2
ALM3: Alarm 3
ALM4: Alarm 4
ALM: OR of alarms 1 to 4
HA: Heater alarm
*1
off
manu
stop
alm1
alm2
alm3
alm4
alm
ha
OFF None
Display Refresh Period d.ref OFF, 0.25, 0.5, 1.0 off, 0.25,
0.5, 1.0
0.25 Second
A-5-6 Protect Level
Parameters Characters Setting (monitor) value Display Default Unit
Operation/Adjustment Protect oapt 0 to 3 0 None
Initial Setting/Communications
Protect
icpt 0 to 2 1 None
Setting Change Protect wtpt OFF, ON off, on OFF None
PF Key Protect pfpt OFF, ON off, on OFF None
Changed Parameters Only chgp OFF, ON off, on OFF None
Parameters Characters Setting (monitor) value Display Default Unit

Omron E5CC-800 Specifications

General

Communication	RS-485 (optional)
Protection Rating	IP66 (front panel)
Input Type	Thermocouple, RTD, analog input
Output Type	Relay, voltage, current
Supply Voltage	100-240 VAC, 24 VAC/VDC
Size	48 x 48 mm
Control Output	Relay, voltage, current
Ambient Operating Temperature	55 °C
Control Method	ON/OFF, 2-PID
Ambient Operating Humidity	35 to 85% RH (non-condensing)
Mounting	Panel mount
