3 Part Names and Basic Procedures
3 - 8
Digital Temperature Controllers (Simple Type) User’s Manual (H211)
On the E5CC/E5EC, the parameters are classified into levels according to their applications. These lev-
els are called setting levels. The setting levels consist of some basic setting levels and other setting lev-
els.
The setting levels are described in more detail in the following tables.
z Basic Setting Levels
The basic setting levels are the levels that are used most frequently.
z Other Setting Levels
The other setting levels are used as required.
The Operation Level, Adjustment Level, Initial Setting Level, and Advanced Function Setting Level
are used most commonly. They are therefore described separately from the other setting levels
under Basic Setting Levels, below.
3-3-3 Setting Levels
What Are Setting Levels?
Application of the parameters Setting level name
Operation
status
Level that is used for operation Operation Level Operating
Level that is used for adjustments Adjustment Level Operating
Level that is used for initial settings Initial Setting Level Stopped
Advanced Function Setting Level
Application of the parameters Setting level name
Operation
status
Level that is used for communications settings Communications Setting Level Stopped
Level that is used for manual operation Manual Control Level Operating
Level that is used to set protection Protect Level Operating
Setting levels
Other setting levels
Operation Level
Adjustment Level
Initial Setting Level
Advanced Function Setting Level
Manual Control Level
Protect Level
Basic setting levels
Communications Setting Level
To Next Page
