A Appendices
A - 2
Digital Temperature Controllers (Simple Type) User’s Manual (H211)
A-1 Specifications
*1 For input setting ranges, refer to A-6 Sensor Input Setting Range, Indication Range, Control Range.
*2 When connecting the ES2-HB/THB, connect it 1:1.
z HB and HS Alarms
(E5CC/E5EC Models with HB and HS Alarms)
*1 HB alarms are not detected and the heater power is not measured if the ON time for the control output for
heating is 100 ms or less (30 ms or less if the control period is 0.1 or 0.2 s).
*2 HS alarms are not detected and the leakage power is not measured if the ON time for the control output
for heating is 100 ms or less (35 ms or less if the control period is 0.1 or 0.2 s).
A-1-1 Ratings
Supply voltage 100 to 240 VAC, 50/60 Hz 24 VAC, 50/60 Hz/24 VDC
Operating voltage range 85% to 110% of rated supply voltage
Power
consumption
E5CC
Option number 800: 5.2 VA max.
Other option numbers: 6.5 VA max.
Option number 800: 3.1 VA max./1.6 W max.
Other option numbers: 4.1 VA max./2.3 W max.
E5EC
Option number 800: 6.6 VA max.
Other option numbers: 8.3 VA max.
Option number 800: 4.1 VA max./2.3 W max.
Other option numbers: 5.5 VA max./3.2 W max.
Sensor input
*1
Thermocouple: K, J, T, E, L, U, N, R, S, B, W, PLII
Platinum resistance thermometer: Pt100, JPt100
Infrared temperature sensor: 10 to 70°C, 60 to 120°C, 115 to 165°C, 140 to 260°C
Current input
*2
: 4 to 20 mA, 0 to 20 mA (Input impedance: 150 Ω max.)
Voltage input
*2
: 1 to 5 V, 0 to 5 V, 0 to 10 V (Input impedance: 1 MΩ min.)
Control output 1/2
Relay
output
E5CC
SPST-NO, 250 VAC, 3 A (resistive load), electrical durability: 100,000 operations
Min. applicable load: 5 V, 10 mA
E5EC
SPST-NO, 250 VAC, 5 A (resistive load), electrical durability: 100,000 operations
Min. applicable load: 5 V, 10 mA
Voltage
output
E5CC
Output voltage 12 VDC ±20% (PNP), max. load current 21 mA, with short-circuit protection
circuit
E5EC
Output voltage 12 VDC ±20% (PNP), max. load current 40 mA, with short-circuit protection
circuit (21 mA if there are two control outputs)
Current output
4 to 20 mA DC, 0 to 20 mA DC, Load: 500 Ω max.
Resolution: Approx. 10,000
Auxiliary output Relay outputs
SPST-NO, 250 VAC, 3 A (resistive load), electrical durability: 100,000 operations
Min. applicable load: 5 V, 10 mA
Control method 2-PID or ON/OFF control
Setting method Digital setting using front panel keys
Indication method 11-segment digital displays and individual indicators
Other functions Depend on the model
Ambient temperature −10 to 55°C (with no condensation or icing); with 3-year guarantee: −10 to 50°C
Ambient humidity 25% to 85%
Storage temperature −25 to 65°C (with no condensation or icing)
Altitude 2,000 m max.
Recommended fuse T2A, 250 VAC, time lag, low shut-off capacity
Installation environment Installation Category II, Pollution Class 2 (IEC 61010-1 compliant)
Max. heater current 50 A AC
Input current readout accuracy ±5% FS ±1 digit max.
Heater burnout alarm setting
range
0.1 to 49.9 A (0.1 A units)
0.0 A: Heater burnout alarm output turns OFF.
50.0 A: Heater burnout alarm output turns ON.
Min. detection ON time
*1
: 30 ms for a control period of 0.1 s or 0.2 s
100 ms for a control period of 0.5 s or 1 to 99 s
Heater short alarm setting
range
0.1 to 49.9 A (0.1 A units)
0.0 A: Heater short alarm output turns ON.
50.0 A: Heater short alarm output turns OFF.
Min. detection OFF time
*2
: 35 ms for a control period of 0.1 s or 0.2 s
100 ms for a control period of 0.5 s or 1 to 99 s
To Next Page
