Parameter Operation Lists
Universal input: Controllers with Thermocouple/Resistance Thermometer Universal Inputs
Analog input: Controllers with Analog Inputs
Operation Level
Parameters Characters Setting (monitor) value Display Default Unit Set value
Process Value Temperature: According to
indication range for each sen-
sor.
Analog: Scaling lower limit
−5% FS to Scaling upper limit
+5% FS
EU
Set Point SP lower limit to SP upper
limit
0EU
Auto/Manual Switch a-m
Multi-SP Set Point
Setting
m-sp 0 to 3 0 None
Set Point During SP
Ramp
sp-m SP lower limit to SP upper
limit
EU
Heater Current 1
Value Monitor
ct1 0.0 to 55.0 A
Heater Current 2
Value Monitor
ct2 0.0 to 55.0 A
Leakage Current 1
Monitor
lcr1 0.0 to 55.0 A
Leakage Current 2
Monitor
lcr2 0.0 to 55.0 A
Program Start prst RSET, STRT rset, strt RSET None
Soak Time Remain sktr 0 to 9999 min or h
RUN/STOP r-s RUN/STOP run, stop Run None
Alarm Value 1 al-1 −1999 to 9999 0 EU
Alarm Value Upper
Limit 1
al1h −1999 to 9999 0 EU
Alarm Value Lower
Limit 1
al1l −1999 to 9999 0 EU
Alarm Value 2 al-2 −1999 to 9999 0 EU
Alarm Value Upper
Limit 2
al2h −1999 to 9999 0 EU
Alarm Value Lower
Limit 2
al2l −1999 to 9999 0 EU
Alarm Value 3 al-3 −1999 to 9999 0 EU
Alarm Value Upper
Limit 3
al3h −1999 to 9999 0 EU
Alarm Value Lower
Limit 3
al3l −1999 to 9999 0 EU
MV Monitor (Heat-
ing)
o −5.0 to 105.5 (standard)
0.0 to 105.0 (heating/cooling)
%
MV Monitor (Cool-
ing)
c-o 0.0 to 105.0 %
