Specifications
Ratings
Supply voltage 100 to 240 VAC, 50/60 Hz 24 VAC, 50/60 Hz/24 VDC
Operating voltage range 85% to 110% of rated supply voltage
Power consump-
tion
E5CN 7.5 VA 5 VA/3 W
E5CN-U 6 VA 3 VA/2 W (4 VA/2 W for current output)
E5AN 10 VA 5.5 VA/4 W
E5EN 10 VA 5.5 VA/4 W
Sensor input (See note 1.) Temperature input type
Thermocouple: K, J, T, E, L, U, N, R, S, B, W, PLII
Platinum resistance thermometer: Pt100, JPt100
Infrared temperature sensor: 10 to 70°C, 60 to 120°C, 115 to 165°C, 140 to 260°C
Voltage input: 0 to 50 mV
Controllers with Analog Inputs (See note 2.)
Current input: 4 to 20 mA, 0 to 20 mA (Input impedance: 150 Ω max.)
Voltage input: 1 to 5 V, 0 to 5 V, 0 to 10 V (Input impedance: 1 MΩ max.)
Control output Relay output E5CN Relay output:
SPST-NO, 250 VAC, 3 A (resistive load), electrical dura-
bility: 100,000 operations
Min. applicable load: 5 V, 10 mA
Long-life relay output (using a triac):
SPST-NO, 250 VAC, 3 A (resistive load), electrical dura-
bility: 1,000,000 operations
Load power supply voltage: 75 to 250 VAC (See note 3.)
Leakage current: 5 mA max. (250 VAC, 60 Hz)
E5CN-U SPDT, 250 VAC, 3A (resistive load), electrical durability:
100,000 operations
Min. applicable load 5 V 10 mA
E5AN
E5EN
Relay output:
SPST-NO, 250 VAC, 5 A (resistive load), electrical dura-
bility: 100,000 operations
Min. applicable load: 5 V, 10 mA
Long-life relay output (using a triac):
SPST-NO, 250 VAC, 3 A (resistive load), electrical dura-
bility: 1,000,000 operations
Load power supply voltage: 75 to 250 VAC (See note 3.)
Leakage current: 5 mA max. (250 VAC, 60 Hz)
Voltage output E5CN
E5CN-U
Output voltage 12 VDC ±15% (PNP), max. load current
21 mA, with short-circuit protection circuit
E5AN
E5EN
Output voltage 12 VDC ±15% (PNP), max. load current 40
mA, with short-circuit protection circuit
Note Control output 2: 12 VDC ±15% (PNP), max. load cur-
rent 21 mA, with short-circuit protection circuit
Current output 4 to 20 mA DC, 0 to 20 mA DC, Load: 600 Ω max.,
Resolution: approx. 10,000
Auxiliary output E5CN
E5CN-U
SPST-NO, 250 VAC, 3 A (resistive load), electrical durability: 100,000
operations
Min. applicable load: 5 V, 10 mA
E5AN
E5EN
SPST-NO, 250 VAC, 3 A (resistive load), electrical durability: 100,000
operations
Min. applicable load: 5 V, 10 mA
Control method 2-PID or ON/OFF control
Setting method Digital setting using front panel keys

Omron E5CN Specifications

General

Communication	RS-485 (optional)
Mounting	Panel Mount
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage (for driving SSR), Current
Display Type	7-segment LED
Size	48 x 48 mm
Control Output	Relay, Voltage (for driving SSR), Current
Alarm Output	1 or 2 outputs
Dimensions	48 x 48 x 78 mm
Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP66
