I/O Configuration and Main Functions Section 1-2
Model Number Structure
Model Number Legend
Note Not all combinations of function 1 and function 2 specifications are possible
for Option Units (E53-@@@@).
*1 Always connect an AC load to a long-life relay output. The output will not
turn OFF if a DC load is connected because a triac is used for switching
the circuit. For details, check the conditions in Ratings.
*2 Auxiliary outputs are contact outputs that can be used to output alarms
or results of logic operations.
Controllers Option Units
1. Control Output 1
R: Relay output
Q: Voltage output (for driving SSR)
C: Current output
Y: Long-life relay output (hybrid) *1
2. Auxiliary Outputs *2
Blank: None
2: Two outputs
3. Option
M: Option Unit can be mounted.
4. Input Type
T: Universal thermocouple/platinum
resistance thermometer
L: Analog current/voltage input
5. Power Supply Voltage
Blank: 100 to 240 VAC
D: 24 VAC/VDC
6. Case Color
Blank: Black
W: Silver
7. Terminal Cover
-500: With terminal cover
1. Applicable Controller
CN: E5CN or E5CN-H
2. Function 1
Blank: None
Q: Control output 2 (voltage for driv-
ing SSR)
P: Power supply for sensor
3. Function 2
Blank: None
H: Heater burnout/SSR failure/Heater
overcurrent detection (CT1)
HH: Heater burnout/SSR failure/
Heater overcurrent detection
(CT2)
B: Two event inputs
03: RS-485 communications
H03: Heater burnout/SSR failure/
Heater overcurrent detection
(CT1) + RS-485 communica-
tions
HB: Heater burnout/SSR failure/
Heater overcurrent detection
(CT1) + Two event inputs
HH03: Heater burnout/SSR failure/
Heater overcurrent detection
(CT2) + RS-485 communications
4. Version
N2: Applicable only to models
released after January 2008
1. Output Type
R: Relay output
Q: Voltage output (for driving SSR)
C: Current output
2. Number of Alarms
Blank: No alarm
1: One alarm
2: Two alarms
3. Input Type
T: Universal thermocouple/platinum
resistance thermometer
L: Analog Input
4. Plug-in type
U: Plug-in type
1
E5CN-@@M@@-@-500
2 3 4 5 6 7 1
E53-CN@@@
2 3 4
1
E5CN-@@@U
2 3 4
