4-2 Document Display
4-11
General Tab Page
Set the document display method and Document storage location
No. Item Details
1 Object Comment Set the comment for the description of pasted objects.
(Up to 32 characters. One-byte and two-byte characters are
counted as one character.)
2 Reference Displays a document file whose number is set with the Document
No.
Click the Set Button to display a Document Table Setting Dialog
Box. Select a document you want to display.
3 Indirect Reference Displays document files using specified communication address
as a document number. Save the document number in binary
format in the address.
When specifying a document number that is not registered in the
document table, the document will not be shown.
4 Alarm/Event Reference Displays documents whose numbers have been set in the Alarm
Event Details Dialog Box when an alarm/event occurs.
If the alarm/event is cleared, the document file will be hidden.
1
2
3
4
To Next Page
