Appendix 1 Specifications
A-10
Item Specification
Communications func-
tions
Data links and message service
Number of data link
words
Transmission area per node:
1,000 words max. (2,000 bytes)
Send/receive data link areas per SYSMAC CS-series PLC:
12,000 words max. (24,000 bytes)
Send/receive data link areas per SYSMAC C200HX/HG/HE, CVM1, or
CV-series PLC:
8,000 words max. (16,000 bytes)
Send/receive data link areas per personal computer:
32,000 words max. (64,000 bytes)
Total send data link words on entire network:
32,000 words max. (64,000 bytes)
Data link areas Bit (CIO, and LR Area), data memory (DM Area), expansion data memory (EM
Area)
Message length 2,012 bytes max.
RAS functions Polling unit backup function
Self-diagnosis (hardware check at startup)
Internode tests and broadcast test (via FINS commands)
Watchdog timer
Error log
Error correction Manchester code check
CRC check (CCITT X
16
+X
12
+X
5
+1)
Note: A Controller Link Interface Unit can be used only for the NS15, NS12, and NS10 NS-
series PTs.
Video Input Specifications
Item Specifications
Input system NTSC (RS-170A compliant) or PAL
Scanning system (See note.) Interlaced
Input signal 1.0 V p-p 75
Signal input connector BNC connector
Note: The NS-series PTs do not support progressive scanning (i.e., non-interlaced scanning)
Item Specifications
Model NS-CA001 NS-CA002
Dimensions 150 x 90 x 21 mm (WxHxD) 150 x 102 x 22 mm (WxHxD)
Weight 0.5 kg or less
Ambient operating
temperature
NS12-V1/-V2 and NS10-V1/-V2
Mounting angle of 0° or greater but
less than 30° to horizontal: 0 to
35°C
Mounting angle of 30° or greater
but less than 90° to horizontal: 0 to
50°C
NS8-V1/-V2
Mounting angle of 0° or greater but
less than 30° to horizontal: 0 to
35°C
Mounting angle of 30° min. but less
than 90° to horizontal plane: 0 to
45°C
Mounting angle of 90° to horizon-
tal: 0 to 50°C
NS12-V1/-V2, NS10-V1/-V2,
and NS8-V1/-V2
Mounting angle of 0° or
greater but less than 30° to
horizontal: 0 to 35°C
Mounting angle of 30° or
greater but less than 90° to
horizontal: 0 to 45°C
Mounting angle of 90° to hori-
zontal: 0 to 50°C
Ambient storage
temperature
20 to 60°C
