3-6 Using Memory Cards
3-23
3-6-1 Installation
NS15
1. Loosen the Memory Card bracket screw shown in the figure below and push the Mem-
ory Card firmly into the back of the slot.
Eject button
2. Tighten the Memory Card bracket screw.
The tightening torque is 0.6 Nâ‹…m.
NS12/10/8/5
1. The Memory Card is installed in the memory card interface on the side of the PT.
Eject button
Front surface
2. Push the Memory Card firmly into the back of the slot. (The eject button will be pushed
out when the Memory Card is installed properly.)
• Removing the Memory Card
NS15
Make sure the Memory Card power indicator is OFF. Loosen the Memory Card bracket
screw and then press the eject button.
NS12/10/8/5
Press the eject button.
To stop the Memory Card from springing out and falling, place your middle finger on the eject
button, and hold the Memory Card with your index finger.
To Next Page
