Appendix 1 Specifications
A-3
Appendix 1 Specifications
A-1-1 General Specifications
Specifications
Item
NS15-TX01@-V2
NS12-TS0@-V1
NS12-TS0@-V2
NS10-TV0@-V1
NS10-TV0@-V2
NS8-TV@@-V1
NS8-TV0@-V2
NS5-SQ0@-V1
NS5-SQ@@-V2
NS5-TQ@@-V2
NS5-MQ@@-V2
Rated power
supply voltage
24 VDC
Allowable volt-
age range
20.4 to 27.6 VDC (24 VDC ±15%)
Allowable input
power interrup-
tion time
No restriction.
Power consump-
tion
45 W max. 25 W max
15 W max.
Ambient operat-
ing
temperature
0 to 50°C (See notes 1, 2, and 3.)
Storage tempera-
ture
−20 to 60°C (See note 2.)
Ambient operat-
ing
humidity
35% to 85% (0 to 40°C) with no condensation
35% to 60% (40 to 50°C) with no condensation
Operating envi-
ronment
No corrosive gases.
Noise immunity
Conforms to IEC61000-4-4, 2 KV (power lines)
Vibration resis-
tance
(during opera-
tion)
5 to 8.4 Hz with 3.5
mm single ampli-
tude and 8.4 to
150 Hz with 9.8
m/s
2
acceleration
10 times in each of
X, Y, and Z direc-
tions
10 to 57 Hz with 0.075 mm amplitude and 57 to 150 Hz with 9.8 m/s
2
accelera-
tion for 30 min in each of X, Y, and Z directions
Shock resistance
(during opera-
tion)
147 m/s
2
3 times in each of X, Y, and Z directions.
Dimensions 405 × 304 ×
75.8 mm
(W × H × D)
315 × 241 × 48.5 mm (W × H × D) 232 × 177 ×
48.5 mm
(W × H × D)
195 × 142 ×
54 mm
(W × H × D)
Panel cutout
dimensions
Width 383.5
+1
0
×
Height
282.5
+1
0
mm
Panel thickness:
1.6 to 4.8 mm
Width 302
+1
0
×
Height
228
+1
0
mm
Panel thickness:
1.6 to 4.8 mm
Width 302
+1
0
×
Height
228
+1
0
mm
Panel thickness:
1.6 to 4.8 mm
Width
220.5
+0.5
0
×
Height 165.5
+0.5
0
mm
Panel thickness:
1.6 to 4.8 mm
Width 184
+0.5
0
×
Height 131
+0.5
0
mm
Panel thickness:
1.6 to 4.8 mm
Weight 4.2 kg max. 2.5 kg max. 2.0 kg max. 1.0 kg max.
Enclosure rating Front panel: IP65 oil-proof type (equivalent to NEMA4) (See note 4.)
Battery life 5 years (at 25°C)
The SRAM and RTC will be backed up for 5 days after the battery runs low (indicator lights orange).
The SRAM and RTC will be backed up by a super capacitor for 5 minutes after removing the old bat-
tery (i.e., after turning ON power after 5 minutes).
International
standards
EC Directives UL 1604 Class 1 Division 2, EC Directives
Note 1. The operating temperature is subject to the following restrictions, depending on the mount-
ing angle and whether an Expansion Unit is installed or not.
