Appendix 8 Standard Models
A-50
3. An RS-232C Option Board (CP1W-CIF01) is required.
4. A C200HW-COM02/COM04/COM05/COM06(-V1) Communications Board is required.
5. A CQM1H-SCB41 Serial Communications Board is required.
Reference • NS-series RS-485 (two-wire) communications are used to connect to an OMRON
Temperature Controller. The NS-AL002 cannot be used with the NT-series PTs or
PLCs. Connect using RS-422A (4-wire).
CPU Units That Connect in 1:N NT Links via RS-442A to PT Serial Ports
PLC Series Unit Serial Communications Board or
Unit required for connection
CS Series CS1G-CPU42(-V1)
CS1G-CPU43(-V1)
CS1G-CPU44(-V1)
CS1G-CPU45(-V1)
CS1H-CPU63(-V1)
CS1H-CPU64(-V1)
CS1H-CPU65(-V1)
CS1H-CPU66(-V1)
CS1H-CPU67(-V1)
CS1G-CPU42H
CS1G-CPU43H
CS1G-CPU44H
CS1G-CPU45H
CS1H-CPU63H
CS1H-CPU64H
CS1H-CPU65H
CS1H-CPU66H
CS1H-CPU67H
CS1D-CPU65H
CS1D-CPU67H
CS1W-SCB41 Serial Communications
Board
CJ Series CJ1G-CPU42H
CJ1G-CPU43H
CJ1G-CPU44H
CJ1G-CPU45H
CJ1M-CPU11
CJ1M-CPU12
CJ1M-CPU13
CJ1M-CPU21
CJ1M-CPU22
CJ1M-CPU23
CJ1H-CPU65H
CJ1H-CPU66H
CJ1H-CPU67H
CJ1H-CPU65H-R
CJ1H-CPU66H-R
CJ1H-CPU67H-R
CJ2H-CPU64-EIP
CJ2H-CPU65-EIP
CJ2H-CPU66-EIP
CJ2H-CPU67-EIP
CJ2H-CPU68-EIP
CJ1W-SCU31/41 Serial Communica-
tions Unit
CP Series
CP1E-N@@@@-@
CP1L-@@@@@-@
CP1H-@@@@@-@
RS-422A Option Board: CP1W-CIF11
or CP1W-CIF12
To Next Page
