Appendix 8 Standard Models
A-52
PLC Series Unit Serial Communications Board or
Unit required for connection
CJ Series CJ1G-CPU42H
CJ1G-CPU43H
CJ1G-CPU44H
CJ1G-CPU45H
CJ1M-CPU11
CJ1M-CPU12
CJ1M-CPU13
CJ1M-CPU21
CJ1M-CPU22
CJ1M-CPU23
CJ1H-CPU65H
CJ1H-CPU66H
CJ1H-CPU67H
CJ1H-CPU65H-R
CJ1H-CPU66H-R
CJ1H-CPU67H-R
CJ2H-CPU64-EIP
CJ2H-CPU65-EIP
CJ2H-CPU66-EIP
CJ2H-CPU67-EIP
CJ2H-CPU68-EIP
Same as at left (See note 3).
CP Series
CP1E-N@@@@-@ CP1L-@@@@-@ (See note 4.)
CP1H-@@@@-@ (See note 4.)
Note 1. CS-series PLC CPU Units without "-V1" in the model number do not support high-speed
NT Links.
2. A CS1W-SCB21/SCB41 Serial Communications Board or a CS1W-SCU21 Serial Com-
munications Unit is required.
3. A CJ1W-SCU41 Serial Communications Board is required.
4. An RS-232C Option Board (CP1W-CIF01) is required.
