Variable name Meaning Function Data type
Range of
values
Reference
_EIP1_TDLinkAll-
RunSta
CIP Communica-
tions1 All T
ag Data
Link Communications
Status
Indicates that all tag data links are com-
municating in CIP communications 1.
TRUE: Tag data links are communicating
in all connections as the originator.
FALSE: An error occurred in at least one
connection.
Note You can use this system-de-
fined variable only for NX-ser-
ies CPU Units.
BOOL TRUE or
FALSE
page 3-53
_EIP2_TDLinkAll-
RunSta
CIP Communica-
tions2 All T
ag Data
Link Communications
Status
Indicates that all tag data links are com-
municating in CIP communications 2.
TRUE: Tag data links are communicating
in all connections as the originator.
FALSE: An error occurred in at least one
connection.
Note You can use this system-de-
fined variable only for the
NX701 CPU Units and NX102
CPU Units.
BOOL TRUE or
FALSE
page 3-53
_EIP_RegTarget-
Sta[255]
Registered Target
Node Information
NX-series CPU Units: Gives a list of no-
des for which built-in EtherNet/IP connec-
tions are registered for CIP communica-
tions 1.
This variable is valid only when the built-
in EtherNet/IP port is the originator
.
Array[x] is TRUE:
The connection to the node with a target
node ID of x is registered.
Array[x] is FALSE:
The connection to the node with a target
node ID of x is not registered.
NJ-series CPU Units: Gives a list of no-
des for which built-in EtherNet/IP connec-
tions are registered.
This variable is valid only when the built-
in EtherNet/IP port is the originator.
Array[x] is TRUE:
The connection to the node with a target
node ID of x is registered.
Array[x] is FALSE:
The connection to the node with a target
node ID of x is not registered.
ARRAY
[0..255] OF
BOOL
TRUE or
FALSE
page 3-54
_EIP1_RegTarget-
Sta[255]
CIP Communica-
tions1 Registered
T
arget Node Informa-
tion
Gives a list of nodes for which built-in
EtherNet/IP connections are registered
for CIP communications 1.
This variable is valid only when the built-
in EtherNet/IP port is the originator.
Array[x] is TRUE:
The connection to the node with a target
node ID of x is registered.
Array[x] is FALSE:
The connection to the node with a target
node ID of x is not registered.
Note You can use this system-de-
fined variable only for NX-ser-
ies CPU Units.
ARRAY
[0..255] OF
BOOL
TRUE or
FALSE
page 3-54
