Variable name _EIP1_CipErr
Meaning CIP Communications1 Error Global/local Global
Function This is the error status variable for CIP communications 1.
It represents the collective status of the following error flags.
• _EIP1_IdentityErr (CIP Communications1 Identity Error)
• _EIP1_TDLinkCfgErr (CIP Communications1 T
ag Data Link Setting Error)
• _EIP1_TDLinkOpnErr (CIP Communications1 Tag Data Link Connection Failed)
• _EIP1_TDLinkErr (CIP Communications1 Tag Data Link Communications Error)
• _EIP1_TagAdrErr (CIP Communications1 Tag Name Resolution Error)
• _EIP1_MultiSwONErr (CIP Communications1 Multiple Switches ON Error)
Note If a Tag Name Resolution Error occurs, it is recorded in the event log and this variable changes
to TRUE. Refer to Meanings of Error Status Bits on page
3-21 for the meanings of the error
status bits.
Note You can use this system-defined variable only for NX-series CPU Units.
Data type WORD Range of values 16#0000 to 16#00F0
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
You can access this variable from the user program with the following instruc-
tion.
• GetEIPError
Variable name _EIP2_CipErr
Meaning CIP Communications2 Error Global/local Global
Function This is the error status variable for CIP communications 2.
It represents the collective status of the following error flags.
• _EIP2_IdentityErr (CIP Communications2 Identity Error)
• _EIP2_TDLinkCfgErr (CIP Communications2 T
ag Data Link Setting Error)
• _EIP2_TDLinkOpnErr (CIP Communications2 Tag Data Link Connection Failed)
• _EIP2_TDLinkErr (CIP Communications2 Tag Data Link Communications Error)
• _EIP2_TagAdrErr (CIP Communications2 Tag Name Resolution Error)
• _EIP2_MultiSwONErr (CIP Communications2 Multiple Switches ON Error)
Note If a Tag Name Resolution Error occurs, it is recorded in the event log and this variable changes
to TRUE. Refer to Meanings of Error Status Bits on page
3-21 for the meanings of the error
status bits.
Note You can use this system-defined variable only for the NX701 CPU Units and NX102 CPU Units.
Data type WORD Range of values 16#0000 to 16#00F0
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
You can access this variable from the user program with the following instruc-
tion.
• GetEIPError
Variable name _EIP_TcpAppErr
Meaning TCP Application Communications Error Global/local Global
Function This is the error status variable for TCP application communications.
It represents the collective status of the following error flags.
• _EIP_T
cpAppCfgErr (TCP Application Setting Error)
• _EIP_NTPSrvErr (NTP Server Connection Error)
Note Refer to Meanings of Error Status Bits on page
3-21 for the meanings of the error status bits.
Data type WORD Range of values 16#0000 to 16#00F0
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
You can access this variable from the user program with the following instruc-
tion.
• GetEIPError
3 System-defined Variables Related to the Built-in EtherNet/IP Port
3-39
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
3-3 Specifications for Individual System-defined Varia-
bles
3
