Variable name _EIP2_EtnCfgErr
Meaning Port2 Basic Ethernet Setting Error Global/local Global
Function Indicates that the Ethernet communications speed setting (Speed/Duplex) for the communications port 2 is incor-
rect. Or
, a read operation failed.
TRUE: Setting incorrect or read failed.
FALSE: Normal
Note You can use this system-defined variable only for the NX701 CPU Units and NX102 CPU Units.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name _EIP_IPAdrCfgErr
Meaning IP Address Setting Error Global/local Global
Function NX-series CPU Units: Indicates the IP address setting errors for the communications port 1.
TRUE:
• There is an illegal IP address setting.
• A read operation failed.
• The IP address obtained from the BOOTP server is inconsistent.
F
ALSE: Normal
NJ-series CPU Units: Indicates the IP address setting errors.
TRUE:
• There is an illegal IP address setting.
• A read operation failed.
• The IP address obtained from the BOOTP server is inconsistent.
• The default gateway settings are not correct.
FALSE: Normal
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name _EIP1_IPAdrCfgErr
Meaning Port1 IP Address Setting Error Global/local Global
Function Indicates the IP address setting errors for the communications port 1.
TRUE:
• There is an illegal IP address setting.
• A read operation failed.
• The IP address obtained from the BOOTP server is inconsistent.
F
ALSE: Normal
Note You can use this system-defined variable only for NX-series CPU Units.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Related in-
structions
Related in-
structions
---
3 System-defined Variables Related to the Built-in EtherNet/IP Port
3-42
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
