Variable name _EIP1_EtnOnlineSta
Meaning Port1 Online Global/local Global
Function Indicates that the built-in EtherNet/IP port's communications can be used via the communications port 1 (that is,
the link is ON, IP address is defined, and there are no errors.)
TRUE: The built-in EtherNet/IP port’
s communications can be used.
FALSE: The built-in EtherNet/IP port’s communications is disabled due to an error in initial processing, restart
processing, or link OFF status.
Note You can use this system-defined variable only for NX-series CPU Units.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name _EIP2_EtnOnlineSta
Meaning Port2 Online Global/local Global
Function Indicates that the built-in EtherNet/IP port's communications can be used via the communications port 2 (that is,
the link is ON, IP address is defined, and there are no errors.)
TRUE: The built-in EtherNet/IP port’
s communications can be used.
FALSE: The built-in EtherNet/IP port’s communications is disabled due to an error in initial processing, restart
processing, or link OFF status.
Note You can use this system-defined variable only for the NX701 CPU Units and NX102 CPU Units.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name _EIP_TDLinkRunSta
Meaning Tag Data Link Communications Status Global/local Global
Function NX-series CPU Units: Indicates that at least one connection is in normal operation in CIP communications 1.
TRUE: Normal operation
F
ALSE: Other than the above.
NJ-series CPU Units: Indicates that at least one connection is in normal operation.
TRUE: Normal operation
FALSE: Other than the above.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name _EIP1_TDLinkRunSta
Meaning CIP Communications1 Tag Data Link Communi-
cations Status
Global/local Global
Function Indicates that at least one connection is in normal operation in CIP communications 1.
TRUE: Normal operation
F
ALSE: Other than the above.
Note You can use this system-defined variable only for NX-series CPU Units.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
3 System-defined Variables Related to the Built-in EtherNet/IP Port
3-52
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
