Variable name _EIP_TargetPLCModeSta[255]
Meaning Target PLC Operating Mode Global/local Global
Function NX-series CPU Units: Shows the operating status of the target node Controllers that are connected for CIP com-
munications 1, with the built-in EtherNet/IP port as the originator
.
The array elements are valid only when the corresponding Normal Target Node Information is TRUE. If the corre-
sponding Normal Target Node Information is FALSE, it indicates the previous operating status.
Array[x] is TRUE: This is the operating state of the target Controller with a node address of x.
Array[x] is FALSE: Other than the above.
NJ-series CPU Units: Shows the operating status of the target node Controllers that are connected with the built-
in EtherNet/IP port as the originator.
The array elements are valid only when the corresponding Normal Target Node Information is TRUE. If the corre-
sponding Normal Target Node Information is FALSE, it indicates the previous operating status.
Array[x] is TRUE: This is the operating state of the target Controller with a node address of x.
Array[x] is FALSE: Other than the above.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name _EIP1_TargetPLCModeSta[255]
Meaning CIP Communications1 Target PLC Operating
Mode
Global/local Global
Function Shows the operating status of the target node Controllers that are connected for CIP communications 1, with the
built-in EtherNet/IP port as the originator
.
The array elements are valid only when the corresponding Normal Target Node Information is TRUE. If the corre-
sponding Normal Target Node Information is FALSE, it indicates the previous operating status.
Array[x] is TRUE: This is the operating state of the target Controller with a node address of x.
Array[x] is FALSE: Other than the above.
Note You can use this system-defined variable only for NX-series CPU Units.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name _EIP2_TargetPLCModeSta[255]
Meaning CIP Communications2 Target PLC Operating
Mode
Global/local Global
Function Shows the operating status of the target node Controllers that are connected for CIP communications 2, with the
built-in EtherNet/IP port as the originator
.
The array elements are valid only when the corresponding Normal Target Node Information is TRUE. If the corre-
sponding Normal Target Node Information is FALSE, it indicates the previous operating status.
Array[x] is TRUE: This is the operating state of the target Controller with a node address of x.
Array[x] is FALSE: Other than the above.
Note You can use this system-defined variable only for the NX701 CPU Units and NX102 CPU Units.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user pro-
gram
Possible. Related in-
structions
---
3 System-defined Variables Related to the Built-in EtherNet/IP Port
3-56
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
