Setting Description Default
Community name Set the community name.
(Y
ou can use up to 255 single-byte alphanumeric characters.)
public
Version Set the version of the SNMP manager.
• SNMPv1
• SNMPv2C
SNMPv1

Trap 2
If the Use Option is selected for SNMP trap, you need to make the following settings.
Setting Description Default
Trap 2 Specify whether to use the Tap 2 settings.
• Use
• Do not use
Do not use
Specifying method Set the specifying method for the SNMP manager destination for
SNMP traps.
• IP address
• Host name
IP address
IP address Set the IP address of the SNMP manager.
(Set this setting if the Specifying method in the T
rap 2 settings
is set to the IP address Option.)
None
Host name Set the host name of the SNMP manager.
(Set this setting if the Specifying method in the T
rap 2 settings
is set to the Host name Option.)
(Single-byte alphanumeric characters, dots, and hyphens: 200
characters max. with up to 63 single-byte alphanumeric charac-
ters between dots.)
None
Community name Set the community name.
(Y
ou can use up to 255 single-byte alphanumeric characters.)
public
Version Set the version of the SNMP manager.
• SNMPv1
• SNMPv2C
SNMPv1
