Omron NX102-12 Series - Page 291

CIPOpen_instance.Error
CIPWrite_
instance.Busy
Determine if instruction execution is completed.
Accept trigger.
OperatingEnd
CIPOpen_instance.Done
CIPRead_instance.Error
CIPSend_instance.Error
CIPClose_instance.Error
CIPWrite_instance.Error
Trigger
CIPOpen_
instance.Busy
CIPRead_
instance.Busy
CIPWrite_instance.Done
CIPRead_instance.Done CIPClose_instance.Done
CIPSend_instance.Done
Operating
CIPSend_
instance.Busy
OperatingEnd
Set Q1
Reset1
RS_instance
RS
CIPClose_
instance.Busy
8 CIP Message Communications
8-29
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
8-2 CIP Message Communications Client Function
8
8-2-8 Sample Programming for CIP Connection (Class 3) Message Communications
