Attribute ID Parameter name Description Attribute
Read data
Data
type
Value
04 hex Revision Device revision Read Struct ---
Major Revision Major revision Read USINT Refer to (2) Major and Minor
CIP Revisions, below
.
Minor Revision Minor revision Read USINT
05 hex Status Status of the built-in Ether-
Net/IP port
Read WORD Refer to (3) Status Details of
the Built-in EtherNet/IP Port,
below
.
06 hex Serial Number Serial number Read UDINT Set value
07 hex Product Name Product name Read STRIN
G
Set value
1. Product Codes for Each Model
Model Product Code
NX701-££££
067D hex
NX102-1200 0BBB Hex
NX102-1100 0BBA Hex
NX102-1000 0BB9 Hex
NX102-9000 0BB8 Hex
NX1P2-££££
068B hex
NJ501-13££
0665 hex
NJ501-14££
0666 hex
NJ501-15££
0667 hex
NJ301-11££
066B hex
NJ301-12££
066C hex
NJ101-££££
0680 hex
2. Major and Minor CIP Revisions
Unit version
CIP revisions
Major revision Minor revision
Unit version 1.00 01 hex 01 hex
Unit version 1.01 or 1.02 03 hex
Unit version 1.03 to 1.08 02 hex 01 hex
Unit version 1.09 02 hex
Unit version 1.10 03 hex
Unit version 1.11 or 1.12 04 hex
Unit version 1.13 to 1.20 05 Hex
Unit version 1.21 or later 06 Hex
3. Status Details of the Built-in EtherNet/IP Port
Bit Name Description
0 Owned Indicates when the built-in EtherNet/IP port has an open connection as the
target of a tag data link.
1 Reserved Always FALSE.
2 Configured Tag data link settings exist.
3 Reserved Always FALSE.
8 CIP Message Communications
8-49
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
8-5 CIP Object Services
8
8-5-2 Identity Object (Class ID: 01 hex)
