Parameter name Data type Description
Reserved UDINT Reserved
Vendor code UDINT Vendor code
Device type code UDINT Device type code
Product code UDINT Product code of the Unit in which errors occurred
Additional information[0]
to
Additional information[31]
Array of BYTE Attached information (system information) of event.
Reserved[0]
to
Reserved[23]
Array of BYTE Reserved
NX Unit
Parameter name Data type Description
Index UDINT Current error index number
This number is assigned when system event logs
and access event logs are registered.
Unit number USINT Unit number
0000 hex: Controller
0001 to 0020 hex: NX Unit
Event priority USINT Error level
Event occurred time UDINT Error occurred time
Product code UDINT Product code of the Unit in which errors occurred
Event code UDINT Event code
Additional information[0]
to
Additional information[31]
Array of BYTE Attached information (system information) of event.

CIP Error Codes
General sta-
tus code
(hex)
Error name Cause
02 Resource unavailable Resources needed for the object to perform the requested
service were unavailable.
0C Object state conflict The object cannot perform the requested service in its cur-
rent mode/state.
13 Not enough data Data required for the execution of the required service is in-
suf
ficient.
15 Too much data Extra data for the execution of the required service is includ-
ed.
1F Vendor specific error The service could not be executed due to internal reasons.
20 Invalid parameter
• The Unit number is out of the supported range.
• The specification of the number of readout records is out
of the range.
• The Unit does not exist.

Method of Use
1 The following variables are generated and initialized to 0.
8 CIP Message Communications
8-61
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
8-5 CIP Object Services
8
8-5-3 NX Configuration Object (Class ID: 74 hex)
