Controller user event log
Parameter name Data type Description
Index UDINT Event log index number
This number is assigned when system event logs
and access event logs are registered.
Event occurred time ULINT Event occurred time
Event source UINT Event source
Event priority UINT Event level
Event code UDINT Event code
Event priority details UINT Event level details
Additional information[0]
to
Additional information[39]
Array of BYTE Attached information (system information) of event.
Reserved[0]
to
Reserved[31]
Array of BYTE Reserved
NX Unit
Parameter name Data type Description
Index UDINT Event log index number
This number is assigned when system event logs
and access event logs are registered.
Unit number USINT Unit number
0000 hex: Controller
0001 to 0020 hex: NX Unit
Event priority USINT Event level
Event occurred time UDINT Event occurred time
Product code UDINT Product code of the Unit in which event occurred
Event code UDINT Event code
Additional information[0]
to
Additional information[31]
Array of BYTE Attached information (system information) of event.

CIP Error Codes
General sta-
tus code
(hex)
Error name Cause
02 Resource unavailable Resources needed for the object to perform the requested
service were unavailable.
0C Object state conflict The object cannot perform the requested service in its cur-
rent mode/state.
13 Not enough data Data required for the execution of the required service is in-
suf
ficient.
15 Too much data Extra data for the execution of the required service is includ-
ed.
1F Vendor specific error The service could not be executed due to internal reasons.
8 CIP Message Communications
8-65
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
8-5 CIP Object Services
8
8-5-3 NX Configuration Object (Class ID: 74 hex)
