Attribute
ID
Parameter name Description
Attrib-
ute
Read/write data
Data
type
Value
06 hex Interface Control Control settings for the inter-
face.
Read/
W
rite
Struct ---
Control Bits Auto Nego for Ethernet com-
munications that specifies full
duplex.
WORD Refer to (2) Control Bit De-
tails, below
.
Forced Interface Speed Gives the set value of the
Ethernet baud rate.
UINT Reads the set value.
0C hex
*1
HC Interface Counters The number of packets sent/
received through the HC in-
terface.
Read Struct ---
HCInOctets The number of octets re-
ceived through the interface.
This counter is the 64-bit edi-
tion of In Octets.
ULINT Reads the current value.
HCInUnicastPkts The number of unicast pack-
ets received through the inter-
face. This counter is the 64-
bit edition of In Ucast Pack-
ets.
ULINT Reads the current value.
HCInMulticastPkts The number of multicast
packets received through the
interface.
ULINT Reads the current value.
HCInBroadcastPkts The number of broadcast
packets received through the
interface.
ULINT Reads the current value.
HCOutOctets The number of octets sent
through the interface.
ULINT Reads the current value.
HCOutUnicastPkts The number of unicast pack-
ets sent through the interface.
This counter is the 64-bit edi-
tion of Out Octets.
ULINT Reads the current value.
HCOutMulticastPkts The number of multicast
packets sent through the in-
terface.
ULINT Reads the current value.
HCOutBroadcastPkts The number of broadcast
packets sent through the in-
terface.
ULINT Reads the current value.
8 CIP Message Communications
8-79
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
8-5 CIP Object Services
8
8-5-5 Ethernet Link Object (Class ID: F6 hex)
