Omron NX102-12 Series User Manual

LOT NO. DDMYY xxxx Ver.2.00
PORT
1 MAC ADDRESS:
PORT2 MAC ADDRESS:
MAC addresses

NX102 CPU Unit
Indicators
Built-in EtherNet/IP
port 1
Built-in EtherNet/IP
port 2
Built-in EtherCAT
port
PORT1 EtherNet/IP
PORT2 EtherNet/IP
PORT3 EtherCAT
MAC Address Notation
A MAC address is uniquely allocated to each device connected to the Ethernet network. The MAC
address of each built-in EtherNet/IP port is represented in 12-digit hexadecimal format and listed in
the place of the Unit as shown below
.
1 Introduction
1-13
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
1-3 Built-in EtherNet/IP Port
1
1-3-2 Part Names and Functions
