Name Description
Connected time Gives the total connection duration in milliseconds.
Unconnected time Gives the total disconnection duration in milliseconds.
Number of connections (in the
Output T
ag Set Tab Page)
Gives the number of connections.
Number of connected origina-
tors (in the Output T
ag Set
Tab Page)
Gives the number of the connected originator devices.
Originator list (in the Output
T
ag Set Tab Page), Target list
(in the Input Tag Set Tab
Page)
Gives the detailed information of the connected originators.
Originator name (in the
Output T
ag Set Tab Page),
or Produced tag name (in
the Input Tag Set Tab
Page)
Gives no information.
IP address (in the Output
T
ag Set Tab Page), or Re-
mote IP address (in the
Input Tag Set Tab Page)
Gives the IP addresses allocated for the originators.
Connected time (in the
Output T
ag Set Tab Page)
Gives the total duration of connection with the originator in milliseconds.
Unconnected time (in the
Output T
ag Set Tab Page)
Gives the total duration of disconnection with the originator in milliseconds.
Destination IP address (in
the Output T
ag Set Tab
Page)
Gives the destination IP addresses. If the multi-cast connections are used,
its own multi-cast address is displayed.
O->T RPI (packet interval) Gives the RPI of connection from the originator to the target in milliseconds.
T->O Heartbeat transmis-
sion cycle (ms)
Gives the heartbeat transmission period of the connections from the target
to the originator in milliseconds.
O->T Timeout Gives the timeout time for the connections from the originator to the target
in milliseconds.
T->O Timeout Gives the timeout time for the connections from the target to the originator
in milliseconds.
O -> T API (actual packet
interval)
Gives the RPI of connection from the originator to the target in milliseconds.
T->O Actual heartbeat
transmission cycle (ms)
Gives the actual heartbeat transmission period of the connections from the
target to the originator in milliseconds.
O->T Connection ID Gives the connection identification for the connections from the originator to
the target in hexadecimal.
T->O Connection ID Gives the connection identification for the connections from the target to the
originator in hexadecimal.
• Ethernet Information
Tab Page
This tab page displays the communications status at the communications driver level of the built-in
Ethernet/IP port.
The error counter information can be used to confirm whether communications problems have oc-
curred.
Under the Tag Data Link, you can confirm characteristics such as the bandwidth usage (PPS).
Appendices
A-33
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
A-2 Use the Sysmac Studio to Set the Tag Data Links (EtherNet/IP Connections)
A
A-2-5 Checking Communications Status with the Sysmac Studio and Troubleshooting
