11.8 H: TERMINALS
438 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Setting Function Description Ref.
9 @Regeneration
The terminal activates on when the motor is regenerating.
ON : Motor is regenerating.
OFF : Motor is operating or stopped.
699
A @SpeedLimit
The terminal activates when the speed limit is active.
699
B @FreqOutput
The terminal activates when the drive outputs frequency.
ON : The drive outputs frequency.
OFF : The drive does not output frequency.
699
C @Standby
The terminal deactivates after the drive stops operating and after the time set with b8-51 [Standby Mode Wait
Time].
ON : The Run command turns on and the magnetic contactor on the input side turns on.
OFF : The Run command turns off and the drive stops operating. Then, the magnetic contactor on the input side
turns off after the time set with b8-51 [Standby Mode Wait Time] elapses.
700
D LO/RE Status
The terminal activates when the Run command source or frequency reference source is LOCAL.
ON : LOCAL
OFF : REMOTE
700
E EDM Safety
The terminal turns on (safety stop state) when the safety circuit and safety diagnosis circuit are operating correctly
and when terminals H1-HC and H2-HC are off (released).
ON : Safety stop state
OFF : Safety circuit fault or RUN/READY
700
F SpeedAgree1
The terminal turns on when the output frequency is in the range of the frequency reference ± L4-02 [SpAgree Det.
Width].
Note:
The drive uses the motor speed as the reference in CLV.
ON : The output frequency is in the range of “frequency reference ± L4-02.”
OFF : The output frequency does not align with the frequency reference although the drive is running.
701
10 USpeedAgree1
The terminal activates when the output frequency is in the range of L4-01 [SpAgree Det.Level] ± L4-02 [SpAgree
Det.Width] and in the range of the frequency reference ± L4-02.
Note:
• The detection function operates in the two motor rotation directions.
• In CLV, the forward/reverse detection level is the value of “Motor Speed ± L4-02.”
ON : The output frequency is in the range of “L4-01 ± L4-02” and the range of frequency reference ± L4-02.
OFF : The output frequency is not in the range of “L4-01 ± L4-02” or the in the range of frequency reference ± L4-
02.
701
11 SpeedAgree2
The terminal activates when the output frequency is in the range of the frequency reference ± L4-04 [SpAgree Det.
Width(+/-)].
Note:
The drive uses the motor speed as the reference in CLV and CLV/PM.
ON : The output frequency is in the range of “frequency reference ± L4-04”.
OFF : The output frequency is not in the range of “frequency reference ± L4-04”.
702
12 USpeedAgree2
The terminal activates when the output frequency is in the range of L4-03 [SpAgree Det.Level(+/-)] ± L4-04
[SpAgree Det.Width(+/-)] and in the range of the frequency reference ± L4-04.
ON : The output frequency is in the range of “L4-03 ± L4-04” and the range of frequency reference ± L4-04.
OFF : The output frequency is not in the range of “L4-03 ± L4-04” or the in the range of frequency reference ± L4-
04.
702
13 FreqDetect 1
The terminal turns off when the output frequency is higher than the value of L4-01 [SpAgree Det.Level] + L4-02
[SpAgree Det.Width]. After the terminal turns off, the terminal continues to remain off until the output frequency
reaches the level set with L4-01.
Note:
• The detection function operates in the two motor rotation directions. The value of L4-01 is used as the
forward/reverse detection level.
• In CLV, the motor speed is the reference.
ON : The output frequency is less than the value of L4-01 or does not exceed the value of L4-01 + L4-02.
OFF : The output frequency exceeds the value of L4-01 + L4-02.
703
14 FreqDetect 2
The terminal activates when the output frequency is higher than the setting value of L4-01 [SpAgree Det.Level].
After the terminal activates, the terminal stays on until the output frequency is at the value of L4-01 - L4-02.
ON : The output frequency is higher than the value of L4-01.
OFF : The output frequency is less than the value of “L4-01 - L4-02”, or is less than the value of L4-01.
703
