Omron S8AS

92
Frame Structure Section 6-2
End Code Examples The following examples show some errors and corresponding end codes.
Missing Subaddress, SID, and FINS-mini
■ Command
■ Response
The subaddress is 00 and the end code is 16 (subaddress error).
Subaddress Less than 2 Characters, Missing SID and FINS-mini
■ Command
The subaddress is missing one character.
■ Response
The subaddress is 00 and the end code is 16 (subaddress error).
Subaddress Normal, Missing SID and FINS-mini
■ Command
■ Response
The end code is 14 (format error).
Subaddress Invalid, Missing SID and FINS-mini
■ Command
■ Response
The end code is 16 (subaddress error). The subaddress error code is
returned because the subaddress was received and the subaddress error has
a higher error priority than the format error.
0 1
Node No.
BCC
STX
ETX
0 1 0 0 1 6
Node No. Subaddress BCC
End code
STX
ETX
0 1 0
Node No.
BCC
STX
ETX
0 1 0 0 1 6
Node No. Subaddress BCC
End code
STX
ETX
0 1 0 0
Node No. Subaddress
BCC
STX
ETX
0 1 0 0 1 4
Node No. Subaddress BCC
End code
STX
ETX
0 1 0
A
Node No. Subaddress
BCC
STX
ETX
0 1 0
0
1 6
Node No. Subaddress BCC
End code
STX
ETX
