Omron S8AS User Manual

119
Glossary Appendix A
Seven-segment Display
Symbol Seven-segment
display
Meaning Page
AS as When the power supply is turned ON, this display is shown for
approximately 3 s during the initialization process. When initializa-
tion has finished, the display will change automatically.
8
BIT bit BIT is an abbreviation for “stop bits.”
Sets the number of stop bits for RS-485 communications.
73
BPS bps Sets the baud rate for RS-485 communications. 71
C-T c-t C-T is an abbreviation for “cut off type.”
The abnormal current tripping type can be selected from Standard
(USU), Instantaneous (INS), or Extended (LNG)
62
C-V c-v C-V is an abbreviation for “cutoff value.”
Sets the abnormal current tripping threshold. Setting range: 0.5 to
3.8 A.
60, 61
DWS dws DWS is an abbreviation for “shutdown sequence.”
Sets the shutdown sequence time for each branch output. Setting
range: 0.0 to 99.9s.
67
EGE ege EGE is an abbreviation for “edge.”
It is one of the branch output tripping methods using the external
tripping input (TRG). All branch outputs are cut off according to the
shutdown sequence when the input is turned ON.
40, 69
FUL ful FUL is an abbreviation for “full.”
It is displayed when the remaining lifetime of the maintenance fore-
cast monitor is more than 10 years.
34
HLF hlf HLF is an abbreviation for “half.”
It is displayed when the remaining lifetime of the maintenance fore-
cast monitor is more than 5 years.
34
INI ini INI is an abbreviation for “initial.”
It is an option in the Mode Selection Menu and is displayed when
the protection level is 0. If the ENT Key is pressed, all S8AS
parameters will return to default values.
57
INS ins INS is an abbreviation for “instantaneous.”
It represents instantaneous detection. It is the abnormal current
cutoff type that trips within 20 ms.
62
LEN len LEN is an abbreviation for “length.”
Sets the data length for RS-485 communications.
72
LFE lfe LFE is an abbreviation for “life.”
Sets the number of years for the maintenance forecast monitor
function to output an alarm. (0.5 to 5.0 years.)
64
LNG lng LNG is an abbreviation for “date long.”
It represents extended detection. It is the abnormal current cut off
type that trips within 1,000 ms.
62
LVL lvl LVL is an abbreviation for “level.”
It is one of the branch output tripping methods using the external
tripping input (TRG). All branch outputs are cut off according to the
shutdown sequence when the input is turned ON or turned OFF.
40, 69
PRT prt PRT is an abbreviation of “protect.”
It is an option in the Mode Selection Menu that must be selected to
change the protection level.
57, 59
PTY pty PTY is an abbreviation for “parity bit.”
Sets the parity for RS-485 communications.
74
RST rst RST is an abbreviation of “reset.”
Press the Reset Key after an abnormal tripping event. The RST
indicator will flash while the error is cleared.
76
