120
Glossary Appendix A
RUN run Run is an option in the Mode Selection Menu which is selected
when entering Run Mode.
57
SET set SET is an abbreviation for “setting.”
It is an option in the Mode Selection Menu that is selected when
entering Setting Mode.
57, 60
SWT swt SWT is an abbreviation for “send waiting time.”
Sets the communications waiting time for RS-485 communications.
75
TMP tmp TMP is an abbreviation for “temperature.”
The Over-temperature Output (TMP) photoswitch output will turn
OFF if the temperature exceeds the set value.
50, 65
TGS tgs Trigger-Sense
Sets the tripping input detection method for TRG. There are two
types of detection methods, EGE and LVL.
69
TRG trg TRG is an abbreviation of “trigger.”
Determines for each branch output whether it can be cut off using
an external input signal.
17, 50,
68
TST tst TST is an abbreviation for “test.”
It is an option in the Mode Selection Menu that is selected when
entering Test Mode.
57
UNO uno UNO is an abbreviation for “unit number”
Sets the unit number for RS-485 communications.
70
UPS ups UPS is an abbreviation of “startup sequence.”
It sets the connection delay time for each branch output. Setting
range: 0.0 to 99.9s
66
USU usu USU is an abbreviation for “usually.”
It is a cutoff type (C-T) for abnormal current tripping. It trips within
100 ms.
62
V-U v-u V-U is an abbreviation for “voltage under.”
It sets the undervoltage detection threshold value. If the output
voltage falls below this set value, the seven-segment display
shows the error code A21 and the undervoltage detection output
(LOW) photoswitch output turns OFF.
63
Symbol Seven-segment
display
Meaning Page
