Multi-Function Input Selection 1
Setting range 0to14 Factory setting 1 (fault reset)
Multi-Function Input Selection 2
Setting range 1to14 Factory setting 2 (external
fault: contact a)
Multi-Function Input Selection 3
Setting range 1to15 Factory setting 4 (multi-step
speed com-
mand 1)
One of the following values can be selected for n06 to n08:
Value Description
0 Override (for n06 only) see note 2
1 Fault reset (fault reset when ON)
2 External fault (contact a: external fault when ON)
3 External fault (contact b: external fault when OFF)
4 Multi-step speed command 1
5 Multi-step speed command 2
6 Multi-step speed command 3 (also serves as an acceleration/deceleration
time changeover command)
8 Acceleration/Deceleration time changeover command
(acceleration/deceleration time 2 when ON)
9 External base block command (base block when ON)
10 External base block command (base block when OFF)
11 Search command from maximum frequency
12 Search command from preset frequency
13 Acceleration/Deceleration-inhibit command (inhibits
acceleration/deceleration and maintains output frequency when ON)
14 Local/Remote changeover (local when ON) see note 4
15 Up/Down command (for n08 only) see note 3
Note 1. The same value cannot be allocated to more than one constant (multi-function
input selection).
Note 2. If “0” (override) is set in n06, the n07 and n08 settings become invalid.
Note 3. If “15” is set in n08, the n07 setting becomes invalid, and multi-function input 2
and multi-function input 3 are set to the up and down commands, respectively.
Note 4. To select value 14 (local/remote changeover), always set “1” in n02.
Chapter 4
