List of Constants Used with 3G3EV SYSMAC BUS Model
Constant
no.
Indi-
cators
Description Setting range Setting
n01 Constant
w
r
i
t
e
-
i
n
h
i
b
i
t
0: Only n01 can be set.
w
r
i
t
e
-
i
n
h
i
b
i
t
selection
/
c
o
n
s
t
a
n
t
1: All constants can be set.
/constant
initialization
8: Constant settings are initialized.
n02 Mode operation
selection
Run command Frequency
reference
s
e
e
c
t
o
0 Digital Operator Digital Operator
1 Communication Digital Operator
n03 Stop mode
0: Deceleration stop
selection
1: Free running
n04 Forward
/Reverse
: forward rotation
/
R
e
v
e
r
s
e
rotation
selection
: reverse rotation
n06 Multi-function
0: Override
input selection 1
1: Fault reset
2: External fault (external fault when
ON)
3: External fault (external fault when
OFF)
4: Multi-step speed command 1
5: Multi-step speed command 2
6: Multi-step speed command 3
8: Acceleration/deceleration time
changeover command
9: External base block command (base
block when ON)
10:External base block command (base
block when OFF)
11:Search command from maximum
frequency
12:Search command from preset
frequency
13:Acceleration/deceleration-inhibit
command
14:Local/remote changeover command
n07 Multi-function
input selection 2
1 to 14: Same as for n06 [2]
Invalid when n06 = “0” or n08 = “15”
 
