Constant
no.
SettingSetting rangeDescriptionIndi-
cators
n08 Multi-function
input selection 3
1 to 14: Same as for n06 [4]
15: Up/down command
Invalid when n06 = “0”
n09 Multi-function
0: Fault occurrence
output selection
1: Operation in progress
1
2: Frequency matching
3: Idling
4: Frequency detection (output
frequency frequency detection
level set in n53)
5: Frequency detection (output
frequency frequency detection
level set in n53)
6: Over-torque being monitored
7: Base block in progress
8: Undervoltage (UV) being monitored
9: Speed search
10:Run mode
11:Normal
n10 Multi-function
output selection
2
0 to 11: Same as for n09 [2]
n11 Frequency
reference 1
0.0 to 400 (Hz) [6.0]
n12 Frequency
reference 2
0.0 to 400 (Hz) [0.0]
n13 Frequency
reference 3
0.0 to 400 (Hz) [0.0]
n14 Frequency
reference 4
0.0 to 400 (Hz) [0.0]
n15 Frequency
reference 5
0.0 to 400 (Hz) [0.0]
n16 Frequency
reference 6
0.0 to 400 (Hz) [0.0]
n17 Frequency
reference 7
0.0 to 400 (Hz) [0.0]
n18 Frequency
reference 8
0.0 to 400 (Hz) [40.0]
n20 Acceleration
time 1
0.0 to 999 (seconds) [10.0]
n21 Deceleration
time 1
0.0 to 999 (seconds) [10.0]
Chapter 7
