9-7
Pa-
ram-
eter
No.
Ref-
er-
ence
page
Changes
during
opera-
tion
Default
setting
Unit
of set-
ting
Set-
ting
range
DescriptionName
n39 Multi-func-
tion input 4
(Input termi-
nal S5)
12 External
base block
command
(NO)
ON: Output shut off (while
motor coasting to a stop
and “bb” flashing)
2 to 8,
10 to
22, 34
1 6 No 5-19
nal S5)
13 External
base block
command
(NC)
OFF: Output shut off (with
motor free running and “bb”
flashing)
14 Search com-
mand
(Searching
starts from
maximum
frequency)
ON: Speed search
(Searching starts from n09)
15 Search com-
mand
(Searching
starts from
preset fre-
quency)
ON: Speed search
16 Acceleration/
Decelera-
tion-prohibit
command
ON: Acceleration/Decelera-
tion is on hold (running at
parameter frequency)
17 Local or re-
mote selec-
tion
ON: Local mode (operated
with the Digital Operator)
19 Emergency
stop fault
(NO)
The Inverter stops accord-
ing to the setting in n04 for
interruption mode selection
with the emergency stop in-
put turned ON
20 Emergency
stop alarm
(NO)
ee ege cys p
put turned ON.
NO: Emergency stop with
the contact closed.
NC: Emergency stop with
the contact opened
21 Emergency
stop fault
(NC)
NC: Emergency stop with
the contact opened.
Fault: Fault output is ON
and reset with RESET
input. Alarm output is ON
(tid)
22 Emergency
stop alarm
(NC)
input. Alarm output is ON
(no reset required).
“STP” is displayed (lit with
fault input ON and flashes
with alarm input ON)
34 Up or down
command
Up or down command (set
in n39 only)
By setting n39 to 34, the
set value in n38 is ignored
and the following setting
are forcibly made.
S4: Up command
S5: Down command
List of Parameters Chapter 9
