Omron SYSMAC C200H-NC112 User Manual

33
Example 4:
Other Outputs with a 5-VDC Power Supply
When the Position Control Unit is set to modes 1 or 2, this signal is output for
approximately 20 ms following completion of ORIGIN SEARCH.
B2
B5
A6
B6
5-VDC
power
supply
–
+
OMRON Servomotor Driver R88D-EP
(Marketed in Japan)
13
5 V
28
RESET
Origin adjustment signal Output
This signal is output in mode 3.
B2
B5
A7
B7
5-VDC
power
supply
–+
OMRON Servomotor Driver R88D-EP
(Marketed in Japan)
13
5 V
27
H. RET
Note Use the same power supply for deviation counter reset output and/or origin
adjustment signal output as for pulse output.
Deviation Counter Reset
Output
Wiring Section 2–2
