Regular Payload Series-Hardware Installation Manual TM5 Series 46
5.3.4 Analog In
Analog In only supports a voltage mode and detection range of -10.00 V ~ +10.00 V.
5.3.5 Analog Out
Analog Out only supports a voltage mode and detection range of -10.00 V ~ +10.00 V.
+
-
+
-
